Stoves

Natural heating distribution
Radiant, conduction and natural convection heating

Multifuoco System Plus
Optional forced ventilation kit with four electronic controlled power levels and LCD remote control. Warm air ducting up to 10 m

Multifuoco System
Optional four speed forced ventilation kit with remote control.
Warm air ducting up to 10 m

Tertiary air system
Optimizes combustion and ensures high efficiency with low emission into the atmosphere

Structure
Firebox and door in enamelled steel with grate in cast iron. Fire pit in Aluker

Air Glass System
Self-cleaning ceramic glass resistant up to 750∞C

Easy Cleaning
Quick and easy maintenance, removable ash drawer

Wide screen fire
Wide vision of the fire to provide the right atmosphere

Majolica cladding
Unique large hand-made pieces

GENERAL FEATURES

• Heating: Multifuoco System® with 4 power levels, optional. Hot ductable air / Natural convection
• Front ventilation: adjustable vent
• Cladding: majolica
• Bench in Majolica: optional
• One-piece firebox: steel
• Firebox: Aluker®
• Flue gas deflector / Brazier: Aluker® / cast iron
• Door / Handle: cast iron with ceramic glass resistant to 750°C /coated steel that can be opened with detachable handle
• Removable ash pan: yes
• Standard flue outlet position: top
• Primary and secondary air: adjustable
• Pre-determined tertiary air: pre-heated
• Glass cleaning: continuous air flow
• Ash vacuum cleaner: optional
• Installation: wall – corner
• Wide view of the fire: yes

TECHNICAL DETAILS

• Energy efficiency class A
• Rated output max kW 9,0
• Rated efficiency power % 80,5
• Rated consumption max kg/h 2,7
• Weight kg 150 without shelf      180kg with shelf
• Standard flue outlet Ø cm 15
• Model QUBE 1
